Optoelectronics Optocouplers · VISHAY

VEMD2704 · Optocoupler 940nm

VEMD2704 (Optocoupler 940nm from VISHAY) comes in a 2-SMD, No Lead package. Reference unit price: US$1.00, minimum order 100 pcs. Availability: In stock. Shenzhen Kewei Technology Co., Ltd. supplies this part from Huaqiangbei, Shenzhen, with tiered pricing, small-batch support and full BOM kitting. Prices and lead times are confirmed on inquiry.

VEMD2704 Optocoupler 940nm
Part numberVEMD2704
ManufacturerVISHAY
DescriptionOptocoupler 940nm
Package2-SMD, No Lead
CategoryOptoelectronics / Optocouplers
Reference priceUS$1.00
Min. order100 pcs
AvailabilityIn stock
Reference stock455 pcs

VEMD2704 price and stock (reference)

QuantityReference unit priceLead time
1 pcs and upUS$1.00In stock
10 pcs and upUS$0.818In stock
30 pcs and upUS$0.719In stock
100 pcs and upUS$0.607In stock
500 pcs and upUS$0.557In stock
1000 pcs and upUS$0.534In stock

VEMD2704 specifications

Wavelength940nm
Spectral Range350nm ~ 1100nm
Diode TypePIN
Response Time70ns
Voltage - DC Reverse (Vr) (Max)6 V
Current - Dark (Typ)30pA
Active Area1.51mm²
Viewing Angle134°
Operating Temperature-40°C ~ 85°C

About the Optocoupler 940nm

VEMD2704 is VISHAY's Optocoupler 940nm 2-SMD, No Lead. It isolates two circuits optically - carrying a signal across a barrier with no electrical connection, used for feedback loops and IO isolation. Check the CTR grade and the isolation voltage, and remember these are slow devices - a communication or high-frequency link needs a fast optocoupler or a digital isolator instead. Currently a backorder item; lead time and MOQ are confirmed on inquiry.

VEMD2704 — frequently asked questions

Is VEMD2704 in stock?

Reference availability: 455 pcs, In stock. Stock and lead time are confirmed on inquiry — please contact our sales team for the latest status before ordering.

How much does VEMD2704 cost?

Reference unit price is US$1.00, minimum order 100 pcs. Tiered pricing: 1 pcs and up: US$1.00, 10 pcs and up: US$0.818, 30 pcs and up: US$0.719, 100 pcs and up: US$0.607, 500 pcs and up: US$0.557, 1000 pcs and up: US$0.534. Send us your required quantity for a firm quotation.

What package and brand is VEMD2704?

VEMD2704 is manufactured by VISHAY in a 2-SMD, No Lead package, filed under Optoelectronics / Optocouplers. VEMD2704 is VISHAY's Optocoupler 940nm 2-SMD, No Lead. It isolates two circuits optically - carrying a signal across a barrier with no electrical connection, used for feedback loops and IO isolation. Check the CTR grade and the isolation voltage, and remember these are slow devices - a communication or high-frequency link needs a fast optocoupler or a digital isolator instead. Currently a backorder item; lead time and MOQ are confirmed on inquiry.

What is the minimum order quantity for VEMD2704?

The minimum order quantity for VEMD2704 is 100 pcs. We support small-batch trial runs as well as volume kitting, and can supply full reels, cut tape or loose parts.

Can you suggest an alternative part for VEMD2704?

Yes. Send us the original part number or the key parameters (Wavelength, Spectral Range, Diode Type) and we will come back with pin-compatible alternatives and a quotation.

How do I request a quote for VEMD2704?

Call or WeChat +86 191 2521 1182, email 19125211182@163.com, or upload your BOM on our BOM sourcing page. We normally respond within two working hours, and a formal full-BOM quotation is normally issued within 24 hours.

Do you ship overseas?

Yes. We are based in Huaqiangbei, Shenzhen and ship worldwide by express courier. Tell us your destination and we will quote shipping with the parts.
