RN214-0.8-02-27M · Common Mode Choke 27mH 800mA 2 channels Through-Hole

RN214-0.8-02-27M (Common Mode Choke 27mH 800mA 2 channels Through-Hole from TE Connectivity) comes in a Vertical, 4 PC Pin package. Reference unit price: US$3.10, minimum order 1 piece. Availability: In stock. Shenzhen Kewei Technology Co., Ltd. supplies this part from Huaqiangbei, Shenzhen, with tiered pricing, small-batch support and full BOM kitting. Prices and lead times are confirmed on inquiry.

RN214-0.8-02-27M Common Mode Choke 27mH 800mA 2 channels Through-Hole
Part numberRN214-0.8-02-27M
ManufacturerTE Connectivity
DescriptionCommon Mode Choke 27mH 800mA 2 channels Through-Hole
PackageVertical, 4 PC Pin
CategoryInductors & Ferrite Beads / Common Mode Chokes
Reference priceUS$3.10
Min. order1 pcs
AvailabilityIn stock
Reference stock15 pcs

RN214-0.8-02-27M price and stock (reference)

QuantityReference unit priceLead time
1 pcs and upUS$3.10In stock
10 pcs and upUS$2.72In stock
25 pcs and upUS$2.49In stock

RN214-0.8-02-27M specifications

Filter TypePower Line
Number of Lines2
Inductance @ Frequency27 mH @ 10 kHz
Current Rating (Max)800mA
DC Resistance (DCR) (Max)500mOhm (Typ)
Voltage Rating - AC300V
Operating Temperature-40°C ~ 100°C

About the Common Mode Choke 27mH 800mA 2 channels Through-Hole

RN214-0.8-02-27M is TE Connectivity's Common Mode Choke CMC 27MH 800MA 2LN TH, Vertical, 4 PC Pin package. Typical use is common-mode EMI suppression on the input of a power supply or on a differential data pair. Common-mode impedance is specified at one frequency, so check the curve at the noise frequency you are fighting and confirm the rated current and DCR. Held in stock in Shenzhen; batch and lead time are confirmed on inquiry.

RN214-0.8-02-27M — frequently asked questions

Is RN214-0.8-02-27M in stock?

Reference availability: 15 pcs, In stock. Stock and lead time are confirmed on inquiry — please contact our sales team for the latest status before ordering.

How much does RN214-0.8-02-27M cost?

Reference unit price is US$3.10, minimum order 1 piece. Tiered pricing: 1 pcs and up: US$3.10, 10 pcs and up: US$2.72, 25 pcs and up: US$2.49. Send us your required quantity for a firm quotation.

What package and brand is RN214-0.8-02-27M?

RN214-0.8-02-27M is manufactured by TE Connectivity in a Vertical, 4 PC Pin package, filed under Inductors & Ferrite Beads / Common Mode Chokes. RN214-0.8-02-27M is TE Connectivity's Common Mode Choke CMC 27MH 800MA 2LN TH, Vertical, 4 PC Pin package. Typical use is common-mode EMI suppression on the input of a power supply or on a differential data pair. Common-mode impedance is specified at one frequency, so check the curve at the noise frequency you are fighting and confirm the rated current and DCR. Held in stock in Shenzhen; batch and lead time are confirmed on inquiry.

What is the minimum order quantity for RN214-0.8-02-27M?

The minimum order quantity for RN214-0.8-02-27M is 1 pcs. We support small-batch trial runs as well as volume kitting, and can supply full reels, cut tape or loose parts.

Can you suggest an alternative part for RN214-0.8-02-27M?

Yes. Send us the original part number or the key parameters (Filter Type, Number of Lines, Inductance @ Frequency) and we will come back with pin-compatible alternatives and a quotation.

How do I request a quote for RN214-0.8-02-27M?

Call or WeChat +86 191 2521 1182, email 19125211182@163.com, or upload your BOM on our BOM sourcing page. We normally respond within two working hours, and a formal full-BOM quotation is normally issued within 24 hours.

Do you ship overseas?

Yes. We are based in Huaqiangbei, Shenzhen and ship worldwide by express courier. Tell us your destination and we will quote shipping with the parts.

Related Common Mode Chokes parts

Need RN214-0.8-02-27M?

Genuine parts · small-batch trial runs · full BOM kitting

How to order RN214-0.8-02-27M

Send the quantity and the destination country; sales normally responds within two working hours with the unit price, date code, MOQ (1 pcs) and shipping cost. A formal full-BOM quotation normally follows within 24 hours. Shipping is quoted together with the parts.
