DX07W024JA1R1000 · Wire-to-Board Connector Through-Hole

DX07W024JA1R1000 (Wire-to-Board Connector Through-Hole from JAE Electronics) comes in a Through-Hole package. Reference unit price: US$1.50, minimum order 1 piece. Availability: In stock. Shenzhen Kewei Technology Co., Ltd. supplies this part from Huaqiangbei, Shenzhen, with tiered pricing, small-batch support and full BOM kitting. Prices and lead times are confirmed on inquiry.

DX07W024JA1R1000 Wire-to-Board Connector Through-Hole
Part numberDX07W024JA1R1000
ManufacturerJAE Electronics
DescriptionWire-to-Board Connector Through-Hole
PackageThrough-Hole
CategoryConnectors / Wire-to-Board Connectors
Reference priceUS$1.50
Min. order1 pcs
AvailabilityIn stock
Reference stock88 pcs

DX07W024JA1R1000 price and stock (reference)

QuantityReference unit priceLead time
1 pcs and upUS$1.50In stock
10 pcs and upUS$1.26In stock
30 pcs and upUS$1.11In stock
100 pcs and upUS$0.957In stock
500 pcs and upUS$0.888In stock

DX07W024JA1R1000 specifications

Connector TypeUSB-C (USB TYPE-C)
Number of Contacts24
GenderReceptacle
SpecificationsUSB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed
Mounting TypeBoard Edge, Surface Mount, Right Angle
TerminationSolder
FeaturesBoard Guide
Ingress ProtectionIPX8 - Waterproof
Operating Temperature-30°C ~ 80°C

About the Wire-to-Board Connector Through-Hole

DX07W024JA1R1000 is JAE Electronics's Wire-to-Board Connector Through-Hole. It joins a cable harness to the board - the classic power and signal link between a main board and a battery pack, fan, sensor or sub-board. Confirm pitch and pin count, then whether the header is vertical or right-angle and which mating housing it takes - the two halves are sold as a set. Availability, batch and lead time are confirmed on inquiry.
