DX07S016JA1R1500 · Wire-to-Board Connector 插件
DX07S016JA1R1500 (Wire-to-Board Connector 插件 from JAE Electronics) comes in a 插件 package. Reference unit price: ¥7.2986, minimum order 1 piece. Availability: In stock. Shenzhen Kewei Technology Co., Ltd. supplies this part from Huaqiangbei, Shenzhen, with tiered pricing, small-batch support and full BOM kitting. Prices and lead times are confirmed on inquiry.
| Part number | DX07S016JA1R1500 |
| Manufacturer | JAE Electronics |
| Description | Wire-to-Board Connector 插件 |
| Package | 插件 |
| Category | Connectors / Wire-to-Board Connectors |
| Reference price | ¥¥7.2986 |
| Min. order | 1 pcs |
| Availability | In stock |
| Reference stock | 2,048 pcs |
DX07S016JA1R1500 tiered pricing (reference)
| Quantity | Reference unit price | Lead time |
|---|---|---|
| 1 pcs and up | ¥7.2986 | In stock |
| 3000 pcs and up | ¥6.9504 | In stock |
| 4500 pcs and up | ¥6.7545 | In stock |
| 7500 pcs and up | ¥6.5157 | In stock |
| 10500 pcs and up | ¥6.363 | In stock |
DX07S016JA1R1500 specifications
| Connector Type | USB-C (USB TYPE-C) |
| Number of Contacts | 24 (16+8 Dummy) |
| Gender | Receptacle |
| Specifications | USB 2.0 |
| Mounting Type | Surface Mount, Right Angle; Through Hole |
| Termination | Solder |
| Features | Board Lock |
| Operating Temperature | -40°C ~ 85°C |
| Number of Ports | 1 |
About the Wire-to-Board Connector 插件
JAE Electronics USB-C (USB TYPE-C) USB 2.0 Receptacle Connector 24 (16+8 Dummy) Position Surface Mount, Right Angle; Through H. In stock — 2,048 pcs available.
DX07S016JA1R1500 — frequently asked questions
Reference availability: 2,048 pcs, In stock. Stock and lead time are confirmed on inquiry — please contact our sales team for the latest status before ordering.
Reference unit price is ¥7.2986, minimum order 1 piece. Tiered pricing: 1 pcs and up: ¥7.2986, 3000 pcs and up: ¥6.9504, 4500 pcs and up: ¥6.7545, 7500 pcs and up: ¥6.5157, 10500 pcs and up: ¥6.363. Send us your required quantity for a firm quotation.
DX07S016JA1R1500 is manufactured by JAE Electronics in a 插件 package, filed under Connectors / Wire-to-Board Connectors. JAE Electronics USB-C (USB TYPE-C) USB 2.0 Receptacle Connector 24 (16+8 Dummy) Position Surface Mount, Right Angle; Through H. In stock — 2,048 pcs available.
The minimum order quantity for DX07S016JA1R1500 is 1 pcs. We support small-batch trial runs as well as volume kitting, and can supply full reels, cut tape or loose parts.
Yes. Send us the original part number or the key parameters (Connector Type, Number of Contacts, Gender) and we will come back with pin-compatible alternatives and a quotation.
Call or WeChat +86 191 2521 1182, email 19125211182@163.com, or upload your BOM on our BOM sourcing page. We normally reply with a quotation within two hours.
Yes. We are based in Huaqiangbei, Shenzhen and ship worldwide by express courier. Tell us your destination and we will quote shipping with the parts.
