AC05000001200JAC00 · 120 Ohm, 5 W Axial Wirewound Resistor, ±5%, Pulse Withstanding

AC05000001200JAC00 is a 120 ohm, 5 W axial wirewound resistor with ±5% tolerance, flame-retardant coating and pulse-withstanding construction. The 120 ohm value belongs to a different role than the milliohm shunts normally used for high-current sensing. Verify pulse energy, ambient, mounting and the intended circuit function rather than relying on the old category label.

AC05000001200JAC00 120 Ohm, 5 W Axial Wirewound Resistor, ±5%, Pulse Withstanding
Part numberAC05000001200JAC00
ManufacturerVishay
Description120 Ohm, 5 W Axial Wirewound Resistor, ±5%, Pulse Withstanding
PackageAxial
CategoryResistors / Wirewound Resistor
Reference priceUS$0.999
Min. order100 pcs
AvailabilityIn stock
Reference stock5 pcs

AC05000001200JAC00 price and stock (reference)

QuantityReference unit priceLead time
1 pcs and upUS$0.999In stock
10 pcs and upUS$0.817In stock
30 pcs and upUS$0.716In stock

AC05000001200JAC00 specifications

Resistance120 Ohms
Tolerance±5%
Power Rating5W
CompositionWirewound
FeaturesFlame Retardant Coating, Pulse Withstand
Dielectric-10/ -80ppm/°C
Operating Temperature-40°C ~ 275°C
Dimensions0.295" Dia x 0.709" L (7.50mm x 18.00mm)

About the 120 Ohm, 5 W Axial Wirewound Resistor, ±5%, Pulse Withstanding

AC05000001200JAC00 is an axial wirewound resistor from Vishay. The listing records 120 ohm, ±5%, 5 W, a flame-retardant coating, pulse-withstanding construction, a -10/-80 ppm/C temperature coefficient and a -40 to 275 C range, with an approximately 7.5 x 18 mm body. This resistance is far above the milliohm range normally used for power-current shunts, so the incorrect subcategory label must not turn it into a low-resistance current-sense part. At an ideal 5 W, 120 ohm corresponds to about 0.204 A and 24.5 V; the usable value still depends on mounting, ambient, pulse waveform and long-term drift. It may be used deliberately for a low-current measurement, but it is not a replacement for a milliohm shunt.

Replacement checks:
  • Confirm whether the design requires a 120 ohm power resistor or a milliohm shunt; the sense voltage, dissipation and layout requirements are completely different.
  • Derate the 5 W rating for the real ambient and mounting method, and check the pulse waveform rather than treating the ideal power as a continuous allowance.
  • Check -10/-80 ppm/C drift, ±5% tolerance and long-term stability against the measurement-error budget; define the actual sense points if it is used for current sensing.
  • Verify axial dimensions, lead forming, flame-retardant coating and heat transfer after soldering; do not compare only 5 W and the outline.
Direct answer: AC05000001200JAC00 is a 120 ohm, 5 W, ±5% axial wirewound resistor with a flame-retardant coating, pulse-withstanding construction and a -40 to 275 C range. It is a higher-resistance power part, not a milliohm high-current shunt. At 5 W the ideal current is only about 0.204 A before derating, so confirm that the circuit genuinely requires 120 ohm. Reviewed 2026-11-20

AC05000001200JAC00 — frequently asked questions

Is AC05000001200JAC00 a low-resistance current shunt?

Not in the low-ohm sense. The listing identifies a 120 ohm, 5 W wirewound resistor. It may be used intentionally for a low-current measurement, but it cannot replace a milliohm high-current shunt.

How much current can a 5 W, 120 ohm resistor carry?

The ideal calculation is about 0.204 A at 24.5 V. Ambient, mounting, pulse and long-term drift require derating, so this is not a continuous operating allowance.

Can another 5 W wirewound resistor replace it directly?

No. Resistance, tolerance, drift, pulse capability, dimensions, mounting, coating and long-term stability all need comparison because they change both measurement and reliability.
